Laser Marking Machines · Laser Marking
CO2 Laser Marking Machine MF-LC Series
MF-LC series CO2 laser marking machine with 30 W / 60 W sources, 50–300 mm marking area and air or water cooling, for plastics, glass and non-metal packaging.
- Supplier: Shenzhen Mufeng Technology Limited Company
- Type: New laser marker (MufengTech)
- Category: Laser Marking
- Price & lead time: on request
Product Details
| Model | MF-LC030/60H/E/D |
| Laser Power | 30w/60w |
| Laser Wavelength | 10.6μm /10.2μm/9.3μm |
| Marking Precision | ≤3-5μ |
| Marking Area | 50-300MM（Can choose other range） |
| Application | Plastic / Glass / Non-metallic material |
| Marking Speed | ≤18000mm/s |
| Min Line Width | 0.02mm |
| Min Character | Adjust freely within marking range |
| Supported Formats | DXF/PLT/AI/PNG/JPG/BMP |
| Machine Power | 600w/1500w |
| Voltage input | 110v-220v/50-60Hz |
| Cooling Mode | Air cooling / water cooling |
Software system
| Laser control system features |
| Hardware time is not lost (working continuously in stock for more than 1 year) |
| Supports network port and serial port communication, touch control and mouse control |
| Operating temperature -10℃ to +60℃ |
| Panel waterproof and dustproof |
| Software support laser state alarm and monitoring |
| Software supports serial communication to turn on and off the laser |
| Support automatic removal of font intersections to achieve perfect laser jet effect |
| Support preview path and line maximum matching line quick check |
| Support path optimization function, customers do not need to move files on the interface, it can automatically adjust to the optimal position |
| Support marking total number shutdown save, boot into marking state and other Settings |
| Multiple languages: Simplified Chinese, traditional Chinese, Korean, Japanese, German, French, Arabic, Spanish, Portuguese, Vietnamese, Persian, Russian, Thai, Polish, and Turkish |
| Supports remote monitoring programs over the network |
| Supports real-time adjustment of information position during marking |
